Trimble X7 3D Laser Scanner

Extend your BIM workflows and precisely capture accurate as-built conditions with the Trimble X7 3D laser scanner powered by Trimble Field Link. The Trimble high-speed 3D laser scanning system includes new innovations to simplify adoption, increase efficiency and provide confidence in the field.

The Trimble® X7 3D Laser Scanner is a compact, lightweight system with new innovations to simplify adoption, increase efficiency and provide confidence in the field. Automatic Calibration ensures data accuracy on each scan and Registration Assist enables automatic in field registration. With the Trimble X7 and Trimble Field Link field software, you get a dependable instrument backed by an industry-leading two-year warranty and comprehensive workflows to validate scan projects in the field.

Applications & Specs

The Trimble X7 combined with Trimble Field Link can help you achieve a variety of tasks including:

  • As-Built Verification
  • Renovations and Tenant Improvement Projects
  • Laser Layout
  • Floor Flatness Verification
  • Scan to BIM
  • Prefabrication Skid QA/QC
  • Precast Set Up Verification
  • Post Tension Cable Verification
  • Deformation of Concrete/Steel Beams and Columns
  • Underground Utilities
  • Facade Studies

Simple, Smart and Professional: Benefits of the Trimble X7

The Trimble X7 offers multiple benefits for construction site operators. Compared to traditional surveying methods, you can capture comprehensive data rapidly. Laser scanning handles all startup processes and transitions for you by replacing manual data entry. Set up your Trimble laser device, capture multiple scans and access your 3D model within minutes.

Other advantages to the Trimble X7 include:

  • A compact and lightweight body for easy transport and mobility.
  • Automated, survey-grade self-leveling.
  • Flexible operation with a tablet or one-button workflow.
  • High sensitivity time-of-flight EDM to effectively capture dark and reflective surfaces.
  • Cost-effective solutions that allow you to create detailed plans before breaking ground. With the Trimble X7, you can create digital plots and scan physical objects to plan your construction project. You can transfer your point clouds to your clients with ease to share your plans, progress and updates.

The Trimble X7 uses the most recent laser technology, making it easy to create 3D models. Technical specifications include:

  • Scanning speed: Up to 500kHz
  • Scan duration: Fastest 1 minute 34 seconds without images, 2 minutes 34 seconds with images
  • Range: 0.6m - 80m
  • Range accuracy: 2mm
  • Range principle: High speed, digital time-of-flight distance measurement

Support

  • Per day $850
  • Per week $3400
  • Per month $6800
